Fiber-to-fiber monochromator
for maximum flexibility in a wide range
  • Wavelength range from UV to MIR
  • Easy change of gratings
  • Optimal transmission
monochromator-f



    Thank you for your request, we will get back to you in a timely manner.

    The Monochromator-F: Powerful technology with a wide spectrum from UV to MIR

    Flexible fiber-to-fiber monochromator

    With our Monochromator-F we have developed a versatile device that offers you clean spectral isolation in a wavelength range from 190 nm to 5.5 µm.

    The high-quality fiber-to-fiber coupling of the monochromator allows flexible integration into all systems, while the design of the optical gratings and their mounts enable easy and fast change.

    We look forward to your enquiry.

    Call us on:
    +49 (0) 0551/270765-0

    Or by email at:
    info@lightsource.tech

    Wellenlängenbereich
    Wavelength range
    190 nm – 5,5 µm
    Halbwertsbreiten

    Bandwidth

    0,7 – 28 nm
    Ein- und Ausgang
    Inputs and outputs
    Fiber-to-fiber
    HighLight
    HighLight
    Easy grating change
    Product Specifications:

    Optical input and output

    SMA connections for multimode fibers (Ø 200 – 1000 µm)
    Focal length
    101.6 mm (4″)
    Aperture
    f/2.7 (for fiber with NA=0.22)
    Wavelength range
    190 nm  – 5.5 µm

    Bandwidth

    0.7 – 28 nm FWHM*
    Grating
    50 x 50 mm² (various gratings available)
    Order sorting filter
    up to 5, ½ Zoll,
    standard set included (3 filters for UV-VIS-NIR)
    Reproducibility
    Typically 0.1 nm*
    Scanning speed
    100 – 300 nm/s*
    Software
    Included with GUI
    Interfaces
    USB/RS-232, LabVIEW™, DLL
    Dimensions
    291 x 182 x 124 mm³, 4 kg
    *Depending on fiber diameter and gratings

    Monochromator-F: Compact and easy-to-integrate fiber-to-fiber monochromator

    Thanks to its fiber-to-fiber coupling, the Monochromator-F is compatible with all fiber-coupled light sources, such as LEDs or laser-pumped plasma light sources.

    The reliably high light throughput of the monochromator and the availability of a wide spectrum from DUV to MIR results in a flexibly tunable point light source with high luminance.

    The optical gratings are optimized for the UV, VIS or NIR / MIR wavelength range and, due to their kinematic mounting, can be quickly and easily changed.

    A motorized filter wheel (up to 5 filters) and a motorized shutter are integrated in the Monochromator-F as standard, with the option of complementing this with a high-speed shutter. The desired wavelength is selected using software control via a USB interface.

    • Fiber-to-fiber: Connection and coupling of fiber-coupled light sources
    • Flexibly tunable point light source
    • Easy change of optical gratings
    • Wavelength range from 190 nm to 5.5 µm (DUV to MIR)
    • Bandwidth from 0.7 to 28 nm
    • Very good transmission and little scattered light in the UV range
    • Including Software, control via USB/RS-232, LabVIEW or DLL
    • Optional high-speed shutter with switching times of up to 10 ms
    datasheet-monochromator F

    Technical data sheet for Monochromator-F

    for fiber coupled light sources



      By submitting this form, I confirm that I have read and understood the privacy policy.

      Thank you for your interest! A link to the data sheet has been send to you.

      Our highLight: Kinematic grating mount

      In order to allow the Monochromator-F to be easily integrated into your workflow, the optical gratings are already pre-adjusted and can be changed in a few simple steps due to our innovative kinematic mounting.
